    Colored Double Reduced Steel Tin Plate / Sheet

    Ask Lasest Price
    Brand Name : SYL
    Model Number : tinplate
    Certification : CE ISO
    Price : $400-680/Metric Ton
    Payment Terms : T/T, Western Union
    Supply Ability : 5000 Ton/Tons per Month
    Delivery Time : 7-15 work days
    • Product Details
    • Company Profile

    Colored Double Reduced Steel Tin Plate / Sheet

    Colored Tin Plate/Tinplate Metal Sheeting Corrugated Sheet House Roofing Sheet Price Sheets Roof Tin Lowes Panels


    Product Description.


    Tinplate(ETP) consists of sheets of steel coated electrolytically with a thin layer of tin. It in itself has strength of steel and the non-corrosive,lustrous,weldable properties of tin.
    ETP may be Single Reduced (SR) or Double Reduced (DR) type and is available both in sheet and /or coil form.
    It certainly is the preferred choice for packaging materials.
    Depending on user requirement tinplate of various types with:
    different formabilities (“tempers”)
    steel thicknesses (from 0.13 mm to 0.65 mm)
    finishes like bright, stone, silver matte, silver bright, matte is available


    Specifications
    Product Name
    Tinplate(SPTE/ETP)
    Standard
    GB, JIS, DIN ,ASTM
    Material
    MR SPCC
    Grade
    Prime
    Annealing
    BA/CA
    Thickness
    0.14-6.0mm
    Width
    600-1500mm
    Temper
    T1, T2, T3, T4, T5, DR7, DR8, DR9, TH550, TH580, TH620, TH660
    Coating(g/m2)
    1.1/1, 2.0/2.0, 2.8/2.8, 2.8/5.6, 5.6/5.6, 8.4/8.4, 11.2/11.2, etc
    Surface Finish
    Stone, Bright, Silver
    Packaging
    Standard export packing.
    or according to customer's requirements.
    Payment
    T/T or L/C or D/P

    Product Introduction

    Tinplate(SPTE) is a common name for electroplated tin steel sheets, which refers to cold-rolled low-carbon steel sheets or strips coated with commercial pure tin on both sides. Tin mainly acts to prevent corrosion and rust. It combines the strength and formability of steel with the corrosion resistance, solderability and aesthetic appearance of tin in a material with corrosion resistance, non-toxicity, high strength and good ductility.Tin-plate packaging has a wide range of coverage in the packaging industry because of its good sealing, preservation, light-proof, ruggedness and unique metal decoration charm. Because of its strong antioxidant, diverse styles and exquisite printing, tinplate packaging container is popular with customers, and widely used in food packaging, pharmaceutical packaging, commodity packaging, instrument packaging, industrial packaging and so on.

    Colored Double Reduced Steel Tin Plate / SheetColored Double Reduced Steel Tin Plate / Sheet

    Mechanical Properties
    emper Grade
    Hardness(HR30Tm)
    Yield Strength(MPa)
    T-1
    49±3
    330
    T-2
    53±3
    350
    T-3
    57±3
    370
    T-4
    61±3
    415
    T-5
    65±3
    450
    T-6
    70±3
    530
    DR-7M
    71±5
    520
    DR-8
    73±5
    550
    DR-8M
    73±5
    580
    DR-9
    76±5
    620
    DR-9M
    77±5
    660
    DR-10
    80±5
    690

    Coating Weight


    Former Coating Designation
    Nominal Coating Weight
    (g/m2)
    Minimum average Coating Weight (g/m2)
    10#
    1.1/1.1
    0.9/0.9
    20#
    2.2/2.2
    1.8/1.8
    25#
    2.8/2.8
    2.5/2.5
    50#
    5.6/5.6
    5.2/5.2
    75#
    8.4/8.4
    7.8/7.8
    100#
    11.2/11.2
    10.1/10.1
    25#/10#
    2.8/1.1
    2.5/0.9
    50#/10#
    5.6/1.1
    5.2/0.9
    75#/25#
    5.6/2.8
    5.2/2.5
    75#/50#
    8.4/2.8
    7.8/2.5
    75#/50#
    8.4/5.6
    7.8/5.2
    100#/25#
    11.2/2.8
    10.1/2.5
    100#/50#
    11.2/5.6
    10.1/5.2
    100#/75#
    11.2/8.4
    10.1/7.8
    125#/50#
    15.1/5.6
    13.9/5.2

    Applications

    Tinplate is primarily used for packaging foodstuffs and beverages, but it is also used in containers for oils, grease, paints, polishes, chemicals and many other products. Aerosol containers and caps and closures are also made from ETP.
