    JIS G3303 MR Grade 2.8g Electrolytic Tin Plate Roll Tinplate In Sheet For Food Cans

    JIS G3303 MR Grade 2.8/2.8g Electrolytic Tin Plate Roll Tinplate in Sheet for food cans


    Product Introduction


    Tinplate is a thin steel coated with tin. Tinplate is characterized by its beautiful metallic luster as well as excellent properties in corrosion resistance, solderability and weldability. TFS is electrolytic chromium coated steel, which has a superior paintability and paint adhesion. TMBP si also our prodcut. Many customers would like to buy TMBP from us then process by themselves.


    Specifications

    Product Name

    JIS G3303 MR Grade 2.8/2.8g Electrolytic Tin Plate Roll Tinplate in Sheet for food cans

    Standard

    JIS

    Material

    MR

    Grade

    Prime

    Annealing

    BA/ CA

    Thickness

    0.16-0.58mm

    Width

    As customer required

    Temper

    T1, T2, T3, T4, T5, DR8, DR9

    Coating(g/m2)

    2.8g/m2

    Surface Finish

    Stone, Bright, Sliver, Matte

    Packaging

    Standard export packing or according to customer's requirements.

    Payment

    T/T or L/C


    JIANGSU SENYILU METAL MATERIAL CO., LTD supplies different specifications of Double reduced (DR) tinplate and Single reduced (SR) tinplate. It can be used in many parts,such as food can, oil can and caps. At present, tinplates have been exported to many countries around the world, such as Egypt, Iran, Myanmar, Thailand and other countries. It is widely used in food packaging and chemical product packagings. We can provide high-quality tinplate that meets international standards.


    Coating Structure

    Production Process


    Mechanical Properties

    Temper Grade

    Hardness(HR30Tm)

    Yield Strength(MPa)

    T-1

    49±3

    330

    T-2

    53±3

    350

    T-3

    57±3

    370

    T-4

    61±3

    415

    T-5

    65±3

    450

    T-6

    70±3

    530

    DR-7M

    71±5

    520

    DR-8

    73±5

    550

    DR-8M

    73±5

    580

    DR-9

    76±5

    620

    DR-9M

    77±5

    660

    DR-10

    80±5

    690


    Coating Weight

    Former Coating Designation

    Nominal Coating Weight
    (g/m2)

    Minimum average Coating Weight (g/m2)

    10#

    1.1/1.1

    0.9/0.9

    20#

    2.2/2.2

    1.8/1.8

    25#

    2.8/2.8

    2.5/2.5

    50#

    5.6/5.6

    5.2/5.2

    75#

    8.4/8.4

    7.8/7.8

    100#

    11.2/11.2

    10.1/10.1

    25#/10#

    2.8/1.1

    2.5/0.9

    50#/10#

    5.6/1.1

    5.2/0.9

    75#/25#

    5.6/2.8

    5.2/2.5

    75#/50#

    8.4/2.8

    7.8/2.5

    75#/50#

    8.4/5.6

    7.8/5.2

    100#/25#

    11.2/2.8

    10.1/2.5

    100#/50#

    11.2/5.6

    10.1/5.2

    100#/75#

    11.2/8.4

    10.1/7.8

    125#/50#

    15.1/5.6

    13.9/5.2


    Applications

    Tinplate is primarily used for packaging food stuffs and beverages, it is also used in containers for oils, grease, paints, polishes, chemicals and many other products. Aerosol containers and caps and closures are also made from ETP plate.



    FAQ:


    Q1. What are your company's main products ?

    A1: Our main products are stainless steel plate/sheet, coil, round/square pipe, bar, channel, etc.

    Q2. How do you control quality ?

    A2: Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS.

    Q3. What are the advantages of your company ?

    A3: We have many professionals, technical personnel, more competitive prices and best after-dales service than other stainless steel companies.

    Q4. How many coutries you already exported ?

    A4: Exported to more than 50 countries mainly from America, Russia, UK, Kuwait, Egypt, Turkey, Jordan,India, etc.

    Q5. Can you provide sample ?

    A5: We can provide the samll samples in stock for free, as long as you contact us.

    Customized samples will take about 5-7days.
